Magnet Bumi Langka Silinder Besar 0.3mm 0.8mm, Magnet Neodymium N52 Besar

Name: Magnet Bumi Langka Silinder Besar 0.3mm 0.8mm, Magnet Neodymium N52 Besar
Brand: Chongqing Great Well Magnet Co.,ltd.
SKU: Magnet neodymium
Price: 99.50 USD
Availability: InStock

Key Attributes

Nama merek:Great wall

Nomor Model:Magnet neodymium

Place of Origin:Chongqing, Tiongkok

Minimum Order Quantity:100 Potongan/potongan

Price:$0.50 - $200.00 / Piece

Supply Ability:1000000 Potongan/potongan per Bulan

Standard Packaging:Paket perisai magnet untuk pengiriman Express dan Udara dengan meletakkan lembaran/pelat besi di ant

Product Summary

Bentuk Kustom Besar 0.3mm 0.8mm Cylinder Neodymium Magnet 40X40X20 Magnet N52 Parameter Produk Nama Produk Bentuk Kustom Besar 0.3mm 0.8mm Cylinder Neodymium Magnet 40X40X20 Magnet N52 Tempat asal Chongqing, Tiongkok Ukuran Disesuaikan Aplikasi sensor/pendidikan/sains Bahan AlNiCo Sertifikasi ROHS ...

Product Details

Menyoroti:

magnet tanah jarang berbentuk silinder

magnet tanah jarang berbentuk silinder n52

magnet neodymium n52 besar

Type: Permanen, permanen

Composite: Magnet Neodymium, Magnet Neodymium

Shape: Lembaran, lembaran, busur, blok, koil, cakram

Application: Magnet Industri

Tolerance: ±20%, 0,01mm ~ 0,05mm

Processing Service: Pemotongan

Grade: Magnet Neodymium, N40 n50 n52 n54

Size: Ukuran Magnet yang Disesuaikan

Color: Perak

Packing: karton

Max Working Temperature: 80-120

Usage: Magnet Industri

Port: Shanghai

Deskripsi Produk

Detailed Specifications & Features

Bentuk Kustom Besar 0.3mm 0.8mm Cylinder Neodymium Magnet 40X40X20 Magnet N52

Parameter Produk

Nama Produk	Bentuk Kustom Besar 0.3mm 0.8mm Cylinder Neodymium Magnet 40X40X20 Magnet N52
Tempat asal	Chongqing, Tiongkok
Ukuran	Disesuaikan
Aplikasi	sensor/pendidikan/sains
Bahan	AlNiCo
Sertifikasi	ROHS
Toleransi	0/01---+/-0,05mm
Fitur	Ramah lingkungan
Arah Magnetisasi	Disesuaikan

Kinerja Magnetik

Barang	Nilai	remanen;				pemaksaan;		Kekuatan Pemaksaan;		Produk BH Maks;				Bekerja
		br				HcB		HcJ		(BH) maks				suhu
		KG		T		KOe	KA/m	KOe	KA/m	MGOe		KJ/m		°C
		Maks.	min.	Maks.	min.	KOe	KA/m	KOe	KA/m	Maks	min.	Maks.	min.
n	N40	13.2	12.6	1.32	1.26	10.5	836	>=12	>=954	42	38	334	289	80
	N42	13.5	12.9	1.35	1.3	10.5	836	>=12	>=954	44	40	350	318	80
	N45	13.8	13.2	1.38	1.32	10.5	836	>=12	>=954	46	42	366	334	80
	N48	14.2	13.7	1.43	1.37	10.5	836	>=11	>=876	49	45	390	358	80
	N50	14.5	14.0	1.45	1.4	10.5	836	>=11	>=876	51	47	406	374	<=80
	N52	14.8	14.4	1.48	1.44	10.5	>=836	>=11	>=876	53	49	422	390	<=80
	N55	1.52	14.6	1.52	1.46	9.0	>=716	11.0	>=876	56	52	446	414	<=80
M	N38M	12.8	12.3	1.3	1.23	11.6	>=915	>=14	>=1114	40	36	318	287	<=100
	N40M	13.2	12.6	1.32	1.26	11.8	>=939	>=14	>=1114	42	38	334	289	<=100
	N42M	13.5	12.9	1.35	1.3	12.0	>=955	>=14	>=1114	44	40	350	318	<=100
	N45M	13.8	13.2	1.38	1.32	12.5	>=994	>=14	>=1114	46	42	366	334	<=100
	N48M	14.2	13.7	1.42	1.37	12.8	>=1018	>=14	>=1114	49	45	390	358	<=100
	N50M	14.5	14	1.45	1.4	13.0	>=1042	>=14	>=1114	51	47	406	374	<=100
	N52M	14.8	14.2	1.48	1.42	13.0	>=1035	>=14	>=1114	53	48.5	422	386	<=100
H	N35H	12.5	11.8	1.25	1.18	11.0	>=875	>=17	>=1353	37	33	295	263	<=120
	N38H	12.8	12.3	1.3	1.23	11.6	>=915	>=17	>=1353	40	36	318	287	<=120
	N41H	13.2	12.6	1.32	1.26	11.8	>=939	>=17	>=1274	42	38	334	302	<=120
	N44H	13.7	13	1.37	1.3	12.1	>=963	>=16	>=1274	45	41	358	326	<=120
	N46H	13.8	13.2	1.38	1.32	12.2	>=971	>=16	>=1274	47	43	374	342	<=120
	N48H	14.2	13.7	1.42	1.37	12.7	>=1011	>=16	>=1274	49	45	390	358	<=120
SH	N35SH	12.5	11.8	1.25	1.18	11.0	>=876	>=20	>=1592	37	33	295	263	<=150
	N39SH	13	12.3	1.3	1.23	11.6	>=923	>=20	>=1592	40	36	318	287	<=150
	N42SH	13.2	12.9	1.32	1.26	>=11.8	>=939	>=20	>=1592	42	38	334	302	<=150
	N44SH	13.7	13	1.37	1.3	>=12.1	>=963	>=20	>=1592	45	41	358	326	<=150
	N46SH	13.8	13.4	1.38	1.34	>=12.5	>=965	>=20	>=1592	47	43	374	342	<=150
UH	N33UH	12.2	11.4	1.22	1.14	>=10.7	>=851	>=25	>=1990	35	31	279	2247	<=180
	N35UH	12.5	11.8	1.25	1.18	>=11.0	>=875	>=25	>=1990	37	33	295	263	<=180
	N38UH	13	12.3	1.3	1.23	>=11.6	>=915	>=25	>=1990	40	36	318	287	<=180
	N40UH	13.2	12.6	1.32	1.26	>=10.5	>=836	>=25	>=1990	42	38	334	289	<=180
EH	N30EH	11.7	10.9	1.17	1.09	>=10.2	>=812	>=30	>=2388	32	28	255	223	<=200
	N33EH	12.2	11.4	1.22	1.14	>=10.7	>=851	>=30	>=2388	35	31	279	2247	<=200
	N35EH	12.5	11.8	1.25	1.18	>=11.0	>=875	>=30	>=2388	37	33	295	263	<=200
	N38EH	13	12.2	1.3	1.22	>=11.5	>=915	>=30	>=2387	40	36	318	287	<=200
AH	N28AH	11	10.4	1.1	1.04	>=9,70	>=772	>=35	>=2786	29	26	231	207	<=220
	N30AH	11.7	10.8	1.17	1.08	>=10.2	>=812	>=35	>=2786	32	28	255	223	<=220
	N33AH	12.2	11.4	1.22	1.14	>=10.7	>=851	>=35	>=2786	35	31	279	247	<=220
	N35AH	12.5	11.7	1.25	1.17	>=11.0	>=876	>=35	>=2386	37	33	295	263	<=220
